Overview of Multimodal Models

Multimodal models can process and reason across multiple types of input—text, images, audio, and even video. This lesson explores the current landscape.

What Makes a Model "Multimodal"?

graph TD
    A[Traditional LLM] --> B[Text Input Only]
    B --> C[Text Output Only]

    D[Multimodal LLM] --> E[Text + Images + Audio]
    E --> F[Text Output with Cross-Modal Understanding]

    style A fill:#fff3cd
    style D fill:#d4edda

Key Capabilities:

1. Vision + Language: Understand images and answer questions about them
2. Audio + Language: Process speech and audio context
3. Cross-Modal Reasoning: Connect information across modalities
4. Unified Representation: Shared understanding space

Major Multimodal Models (2024-2026)

GPT-4 Vision (GPT-4V)

Capabilities:

• Text + image understanding
• OCR and diagram interpretation
• Visual question answering
• Chart and graph analysis

Limitations:

• No native audio processing
• Rate limits on vision tokens
• Higher cost for image inputs

# Conceptual usage
response = gpt4v.generate({
    "text": "What's in this image?",
    "image": product_photo.jpg
})

Claude 3.5 Sonnet (Anthropic)

Capabilities:

• Best-in-class vision understanding
• Code generation from screenshots
• Complex document analysis
• Long context window (200K tokens)
• Strong reasoning over multimodal inputs

When to Use:

• High-accuracy requirements
• Complex reasoning tasks
• Large document processing
• Production RAG systems

# Conceptual: Claude with image
response = claude.messages.create({
    "messages": [{
        "role": "user",
        "content": [
            {"type": "text", "text": "Explain this diagram"},
            {"type": "image", "source": diagram.png}
        ]
    }]
})

Gemini 1.5 Pro (Google)

Capabilities:

• Text, image, audio, and video
• Massive context window (1M+ tokens)
• Native video understanding
• Real-time data processing

Unique Strengths:

• Process entire movies
• Multi-hour audio transcripts
• Large codebase analysis

LLaVA and Open-Source Models

Models:

• LLaVA (Large Language and Vision Assistant)
• BakLLaVA
• CogVLM

Advantages:

• Fully open source
• Run locally with Ollama
• No API costs
• Complete data privacy

Trade-offs:

• Lower accuracy than commercial models
• Higher compute requirements
• Less mature tooling

Model Capabilities Comparison

Model	Vision	Audio	Video	Context Window	Best For
GPT-4V	✅ Excellent	❌	❌	128K	General purpose
Claude 3.5	✅ Best	❌	❌	200K	Production RAG
Gemini 1.5	✅ Strong	✅	✅	1M+	Long context
LLaVA	✅ Good	❌	❌	32K	Local/private

How Multimodal Models Work

graph LR
    A[Input Data] --> B{Input Type}

    B -->|Text| C[Text Encoder]
    B -->|Image| D[Vision Encoder]
    B -->|Audio| E[Audio Encoder]

    C & D & E --> F[Unified Representation]
    F --> G[Transformer Decoder]
    G --> H[Text Output]

The Architecture

1. Separate Encoders: Each modality has a specialized encoder

   • Vision: Processes images into embeddings (e.g., CLIP)
   • Audio: Converts sound to features (e.g., Whisper)
   • Text: Tokenizes and embeds text

2. Projection Layer: Maps different modalities to shared space

3. Unified Transformer: Processes combined representations

4. Decoder: Generates text responses

Training Process

graph TD
    A[Pretraining] --> B[Vision-Language Datasets]
    B --> C[Image-Caption Pairs]
    B --> D[OCR Datasets]
    B --> E[Diagram-Text Pairs]

    C & D & E --> F[Contrastive Learning]
    F --> G[Aligned Embeddings]

    H[Fine-Tuning] --> I[Instruction Following]
    I --> J[Task-Specific Data]
    J --> K[Production Model]

Pretraining:

• Learn visual concepts
• Align image and text embeddings
• Billions of image-text pairs

Fine-Tuning:

• Task-specific training
• Instruction following
• Safety and alignment

Specialized Capabilities

OCR and Document Understanding

Models can extract text from:

• Scanned documents
• Handwritten notes
• Complex layouts (multi-column, tables)
• Low-quality images

Input: Photo of handwritten receipt
Output: Structured data {date, items, total}

Chart and Diagram Comprehension

graph LR
    A[Chart Image] --> B[Model]
    B --> C[Extract Data Points]
    B --> D[Understand Trends]
    B --> E[Answer Questions]

    F["Revenue Chart"] --> B
    B --> G["Q4 revenue was $2.3M, up 15% QoQ"]

Spatial Reasoning

Models can understand:

• Object positions ("to the left of")
• Relative sizes
• Layouts and arrangements
• 3D perspectives

Code from Screenshots

Input: Screenshot of UI mockup
Output: React/HTML code implementing the design

Embedding Models for Multimodal RAG

Different from generation models, embedding models convert data to vectors:

CLIP (OpenAI)

• Text and image embeddings in shared space
• Enables text-to-image and image-to-text search
• Widely used standard

# Conceptual: CLIP embeddings
text_emb = clip.embed_text("a red car")
image_emb = clip.embed_image(car_photo.jpg)

similarity = cosine_sim(text_emb, image_emb)  # High if image shows red car

ImageBind (Meta)

• Binds 6 modalities: text, image, audio, depth, thermal, IMU
• Enables cross-modal search

Multimodal Embeddings from Gemini/Bedrock

• API-based embedding services
• Optimized for retrieval
• Handle images + text

Choosing the Right Model

graph TD
    A{Requirements} --> B{Privacy Critical?}

    B -->|Yes| C[Local Models]
    B -->|No| D{Budget?}

    C --> E[LLaVA/Ollama]

    D -->|Flexible| F{Use Case?}
    D -->|Limited| G[Open Source]

    F -->|Complex Docs| H[Claude 3.5]
    F -->|Long Context| I[Gemini 1.5]
    F -->|General| J[GPT-4V]

Decision Criteria:

1. Privacy: Local vs Cloud
2. Accuracy: Performance requirements
3. Cost: API pricing
4. Latency: Response time needs
5. Context Length: Document size
6. Modalities: What inputs are needed?

The Future: True Multimodality

Current models are still primarily text-centric with visual understanding bolted on.

Next Generation:

• Native video understanding (not just frame extraction)
• Real-time multimodal streaming
• Audio-visual reasoning
• Cross-modal generation (text → image, image → sound)

Key Takeaways

1. Multimodal models are production-ready for RAG systems
2. Claude 3.5 Sonnet leads in document understanding
3. Gemini excels at long context
4. Open-source options exist for privacy-first deployments
5. Embeddings models are separate from generation models

In the next lesson, we'll deep dive into Claude Sonnet 3.5 and why it's particularly well-suited for multimodal RAG.
