Nodes, Edges, and State Transitions

In this lesson, we transition from theory to syntax. We will learn the "Big Three" of the LangGraph API: the State schema, the Node function, and the Edge router. Mastering these will allow you to build any agentic architecture from scratch.

---

1. Defining the State (The Schema)

The state is a standard Python TypedDict. However, it has a superpower: Reducers.

What is a Reducer?

By default, if you return {"messages": ["Hello"]} from a node, it will overwrite the previous messages. A reducer tells LangGraph how to merge the new data with the old data.

from typing import TypedDict, Annotated
import operator

class AgentState(TypedDict):
    # 'operator.add' is a reducer. It tells LangGraph to
    # APPEND new messages to the existing list.
    messages: Annotated[list, operator.add]

    # This field will be OVERWRITTEN every time
    current_thought: str

---

2. Writing Nodes (The Workers)

A node is just a Python function (usually async) that takes the state and returns a dictionary with the updates.

async def researcher_node(state: AgentState):
    query = state['messages'][-1].content
    # Use a tool or LLM to get data
    results = await my_search_tool.ainvoke(query)

    # Return ONLY what changed
    return {"messages": [results]}

Rule of Thumb: Keep nodes pure. A node should perform one logical task. If a node is doing "Search AND Summarize," break it into two nodes.

---

3. Defining Edges (The Logic)

Edges connect the nodes. There are two types.

A. Static Edges

These always point from one node to another.

workflow.add_edge("researcher", "summarizer")

B. Conditional Edges

These use a Router Function to decide the next path.

def should_continue(state: AgentState):
    # If the LLM outputted a Stop signal, end the graph
    if "STOP" in state["messages"][-1].content:
        return "end"
    return "continue"

workflow.add_conditional_edges(
    "researcher",
    should_continue,
    {
        "continue": "researcher", # Loop back!
        "end": "summarizer"       # Move on
    }
)

---

4. The Graph Compilation

Once you have added your nodes and edges, you must Compile the graph. This transforms your Python definitions into a high-performance execution engine.

from langgraph.checkpoint.memory import MemorySaver

# Add persistence (Module 5.3)
memory = MemorySaver()

# Compile the graph
app = workflow.compile(checkpointer=memory)

---

5. Visualizing the Graph

One of the best features of LangGraph is the ability to generate a visualization of your logic directly in your terminal or Jupyter notebook.

from IPython.display import Image, display

# Generate a Mermaid mermaid diagram
display(Image(app.get_graph().draw_mermaid_png()))

---

6. The Execution Flow: invoke vs stream

• app.invoke(): Runs the entire graph and returns the final state.
• app.stream(): Returns an iterator that yields the updates from every node as they happen. This is the secret to building high-quality UIs.

---

Summary and Mental Model

• The State is your database.
• The Node is your SQL UPDATE statement.
• The Edge is your GOTO or SWITCH logic.

By separating the Logic of Action (Nodes) from the Logic of Movement (Edges), you create a system that is incredibly easy to maintain and scale.

---

Exercise: Implementation Task

1. Coding: Write a Node function called count_tokens that looks at the message history and updates a state key called total_tokens.
2. Logic: Design a Conditional Edge that routes to an Alert_Node if the total_tokens exceeds 10,000.
3. Reducers: Why is operator.add necessary for a list of tool outputs? What would happen if you had 3 parallel tools running and they all tried to update the list without a reducer? Ready for something harder? Let's talk about agents that live for a long time.
