The Boot Sequence: From Power button to Prompt

The first 60 seconds of a computer's life are the most complex. Behind a simple loading bar or a scrolling list of text, Linux is performing a massive orchestration of hardware detection, security verification, and service activation.

If you understand this sequence, you can fix 90% of "Server won't start" issues. You'll know if the problem is a hardware configuration (UEFI), a corrupted menu (GRUB), or a service that refuses to start (systemd).

In this lesson, we will trace the journey of a Linux boot and learn to manage the system's "State" using Targets.

---

1. The Four Acts of the Boot Story

Act 1: Hardware Logic (BIOS/UEFI)

The physical chips on your motherboard wake up and perform a POST (Power-On Self-Test). They look for a "Boot Loader" on your hard drive.

• Modern standard: UEFI (Unified Extensible Firmware Interface).

Act 2: The Choice (GRUB2)

The computer finds GRUB (Grand Unified Bootloader). This is the menu where you can choose which Kernel to run or enter "Recovery Mode."

Act 3: The Kernel Heartbeat

The Kernel loads into RAM, detects your hardware (CPU, RAM, Disk), and mounts the root filesystem (/). It then starts the very first program: PID 1 (systemd).

Act 4: The Orchestration (systemd)

systemd brings the system to a specific "Goal" or Target.

---

2. From Runlevels to Targets

In the old days, Linux used Runlevels (numbered 0-6). Today, systemd uses Targets.

Old Runlevel	systemd Target	Purpose
0	poweroff.target	Shutting down.
1 (Single)	rescue.target	Maintenance (No network, root only).
3 (Multi)	multi-user.target	Standard Server (Networking, no GUI).
5 (Graph)	graphical.target	Standard Desktop (GUI + Networking).
6	reboot.target	Restarting.

---

3. Managing the Current State

You can switch the state of a running server without rebooting.

# See your current default target (usually graphical or multi-user)
systemctl get-default

# Switch to a headless server state immediately
sudo systemctl isolate multi-user.target

# Set the system to ALWAYS boot into the CLI (Server mode)
sudo systemctl set-default multi-user.target

---

4. Troubleshooting: Emergency Mode

If your filesystem is corrupted, Linux might fail to reach the multi-user.target. It will drop you into the emergency.target. Here, the filesystem is usually "Read-Only" so you can't accidentally cause more damage while you try to fix it.

# Mount the filesystem as Read-Write so you can edit config files
mount -o remount,rw /

---

5. Practical: Customizing the GRUB Menu

Sometimes you need to add a "Hidden" kernel option to fix a graphics problem or slow boot. NEVER edit /boot/grub/grub.cfg directly. It is auto-generated.

The Correct Way:

1. Edit /etc/default/grub.
2. Add your options to GRUB_CMDLINE_LINUX_DEFAULT.
3. Run sudo update-grub.

---

6. Example: A Boot Performance Profiler (Python)

If your server takes 5 minutes to boot, it's usually because one service is waiting for a timeout. Here is a Python script that parses systemd's internal timing to flag the "Slowest" parts of your boot.

import subprocess
import re

def analyze_boot_performance():
    """
    Parses systemd-analyze blame to find bottlenecks.
    """
    print("--- Boot Performance Audit ---")
    print(f"{'Service Name':30} | {'Load Time'}")
    print("-" * 50)

    try:
        # systemd-analyze blame lists services by time taken
        result = subprocess.run(['systemd-analyze', 'blame'], capture_output=True, text=True)
        lines = result.stdout.split('\n')

        # Show top 10 bottlenecks
        for line in lines[:10]:
            if line.strip():
                print(line.strip())

    except FileNotFoundError:
        print("systemd-analyze not found. Are you on a systemd linux?")

if __name__ == "__main__":
    analyze_boot_performance()

---

7. Professional Tip: The 'Magic SysRq' Key

If your system is completely frozen and you can't even move the mouse or switch to a terminal, there is a "secret" hardware-level key combination that can safely reboot the server. It's called REISUB. (Hold Alt + SysRq/PrintScreen and slowly type R-E-I-S-U-B). It safely terminates apps, syncs disks, and reboots.

---

8. Summary

The boot sequence is a hand-off between four specialized layers.

• UEFI finds the disk.
• GRUB chooses the OS.
• Kernel starts the hardware.
• systemd reaches the Target.
• Use systemctl isolate to change system states on the fly.
• Use systemctl set-default to define your machine's permanent role (Server vs. Desktop).

In the next lesson, we will look at the final piece of system security: Basic Firewall Management with UFW and Firewalld.

Quiz Questions

1. What is the difference between the multi-user target and the graphical target?
2. Which process is responsible for starting all the services (Nginx, SSH, etc.) after the kernel loads?
3. How do you change a server permanently so it only boots into the command line (multi-user) and not a GUI?

---

Continue to Lesson 5: Firewall Management—UFW and Firewalld.
