High Availability and Disaster Recovery: The Unstoppable Graph

Your Knowledge Graph is the "Collective Brain" of your company. If it goes down, your customer support bots stop responding, your internal researchers lose their map, and your automated agents become paralyzed. For enterprise AI, "Single Server" and "Low Availability" are not options.

In this final lesson of Module 7, we will look at how to build an Unstoppable Graph. We will explore Causal Clustering (The 3-node model), Read Replicas (For scaling millions of users), and Cross-Region Replication (For surviving a total AWS/GCP blackout).

---

1. Causal Clustering: The 3-Node Minimum

In a production environment, you should never run just one graph server. You should run a Cluster (typically 3 or more nodes).

• The Leader: Handles all writes (Updates, New Facts).
• The Followers: Replicate the data and handle all Read Queries from your Graph RAG pipeline.

The Resilience: If the Leader crashes, the Followers hold an election and pick a new Leader in seconds. Your AI agent might see a 2-second delay, but it won't crash.

---

2. Read Replicas: Scaling for Millions

Graph RAG involves heavy read operations.

• Agent Query: "Find all related paths for X." (Computationally expensive).

If you have 1,000 agents running simultaneously, you don't send them to the Leader. you send them to a fleet of Read Replicas. These are "ReadOnly" nodes that sit as close to your AI workers as possible.

---

3. Disaster Recovery (DR): The "North Star" Plan

What happens if an entire datacenter (US-EAST-1) goes offline?

1. Async Replication: Your local graph data is constantly streamed to a different region (e.g., US-WEST-2).
2. DNS Failover: Your Graph RAG code connects to a "Global Endpoint." When Region 1 fails, the traffic is automatically routed to Region 2.

The Catch: Region 2 is usually "Eventually Consistent." It might be 5-10 seconds behind. For most RAG use cases, this is an acceptable tradeoff for total reliability.

graph TD
    User((User)) -->|Query| LB[Load Balancer]

    subgraph "Region 1 (Primary)"
    LB --> R[Leader]
    R -->|Sync| F1[Follower 1]
    R -->|Sync| F2[Follower 2]
    end

    subgraph "Region 2 (Standby)"
    R -.->|Async Replication| DR_S[Standby Node]
    end

    style R fill:#4285F4,color:#fff
    style DR_S fill:#f44336,color:#fff

---

4. Implementation: Configuring a Driver for High Availability

When you connect to a graph cluster from Python, you don't use a single IP. You use a Bolt+Routing or Neo4j:// protocol.

from neo4j import GraphDatabase

# 'neo4j://' protocol automatically finds the
# Leader for writes and the Follower for reads.
URI = "neo4j://core-cluster.company.com:7687"
AUTH = ("neo4j", "password123")

def run_query(query):
    with GraphDatabase.driver(URI, auth=AUTH) as driver:
        # 'execute_read' sends the query to a Follower node
        return driver.execute_read(lambda tx: tx.run(query).data())

# This code is "Fault Tolerant". Even if one server dies,
# the driver will find another one automatically.

---

5. Summary and Exercises

High Availability is the "Insurance Policy" for your AI.

• Clusters protect against server failure.
• Read Replicas handle the massive traffic of agentic workflows.
• Cross-Region DR protects against cloud provider outages.
• Routing Protocols (neo4j://) automate the "Where to go" decision.

Exercises

1. Cluster Math: If a 3-node cluster loses 1 node, is it still operational? What if it loses 2 nodes? (Hint: The concept of "Quorum").
2. Latency vs. Reliability: Why is "Async Replication" to a different region better for global speed than "Sync Replication"?
3. The "Global" Bot: You are building a bot for a global bank. If the London database is 1 hour ahead of the New York database, what happens when an agent in NY asks about a transaction made in London 5 minutes ago?

Congratulations! You have completed Module 7: Graph Storage and Infrastructure. You now have a solid, scalable place to store your "World Model."

In Module 8: Graph Querying for Retrieval, we will learn how to write the "Magic Spells" (Cypher) that extract the perfect context from these clusters.
